6G Research Laboratory

The 6G research Laboratory provides an access to the following measurement and fabrication facilities:

• Rohde & Schwartz ZNA-40 up to 43 GHz;

• Quasi-optical transmittometer, up to 500 GHz;

• Sets of mm-wave extenders and corresponding horns, from 50 to 330 GHz;

• Clinotron, powerful (up to 4W) CW source 93-100 GHz;

• Two probe stations, e.g., Microtech Probe Station;

• LPKF Protolaser U4; the laser PC cutting machine, which can be used to produce PCBs, antennas and cut pure metal sheets. LPKF Protolaser U4



It allows to undertake so-called VNA-spectroscopy, which frequency based and with much higher resolution than TDS systems, however, with very small bandwidths, comparing to the latter.
